KYN61-40.5 Hloov Txee

KYN61-40.5 Hloov Txee ua haujlwm ua haujlwm tseem ceeb hauv 35kV siab-voltage distribution networks. Nws muaj kev nyab xeeb xa hluav taws xob los ntawm qhov chaw ntws mus rau siab -voltage loads, motors, substations, thiab renewable energy connections. Kev sib txuas, kev tiv thaiv, kev saib xyuas, thiab kev sib txuas lus nta hauv ib qho armored, tshem tau AC hlau-pob hauv tsev, nws ua kom muaj tseeb thiab txhim khu kev qha hluav taws xob hauv kev lag luam thiab kev siv hluav taws xob tseem ceeb.

Lub txee siv cov khoom pov thawj tshem tawm cov qauv tsim, ua rau lub tshuab hluav taws xob thiab cov ntsuas ntsuas tau raug tshem tawm ib tus zuj zus rau kev saib xyuas yam tsis cuam tshuam tag nrho cov kab ke. Kev tiv thaiv kev ua haujlwm suav nrog luv luv-circuit, overload, av txhaum, thiab tshaj / hauv qab-voltage scenarios, tso cai rau kev sib cais txhaum sai thiab meej. Advanced rwb thaiv tsev thiab lub kaw lus kaw txhawb kev ua haujlwm ruaj khov thoob plaws ntau qhov kub thiab av noo theem, thaum tiv thaiv plua plav ingress thiab condensation.

Cov Qauv: IEC 62271-200, GB 3906-2006, DL / T 404-2017
Kev ntsuas hluav taws xob: 40.5 kV
Rated tam sim no: 1250A, 1600A, 2000A
Luv luv-Lub Sijhawm Ua Haujlwm Tam Sim No: 25kA / 4s, 31.5kA / 4s
Peak Withstand tam sim no: 63kA, 80kA
Rwb thaiv tsev theem: 95kV (lub zog zaus), 185kV (impulse)
Kev tiv thaiv qib: IP40

Tsim los ntawm 2.0 hli txias- dov steel nrog lub zog welded thav duab, lub txee muaj zog txhua yam ruaj khov thiab kev co kuj. Cov chav tsev sib cais kom meej meej kom muaj kev nyab xeeb thiab txhim khu kev ruaj ntseg, thaum siab - sealing ceev kom tiv thaiv plua plav thiab ya raws. Tus qauv "tsib-kev tiv thaiv" cuam tshuam qhov system ntxiv ib txheej ntxiv ntawm kev nyab xeeb kev ua haujlwm. Nws cov tsheb thauj khoom modular tau hloov pauv tau tag nrho, txo qis sijhawm thiab nqi kho. Txhua KYN61-40.5 Hloov Txee yog xa nrog kev txhawb nqa dav, suav nrog kev sim Hoobkas, kev taw qhia kev teeb tsa, commissioning, thiab kev pab cuam txuas ntxiv.
